Food-Grade Silicone Baby Pacifier and Bottle Production Machine High-Efficiency Liquid Silicone Injection Molding Machine
Features
1,High productivity: Maximum time savings. no delays in vertical machines with a rotary or shuttle table, the next injection process step is performed in parallel with parts handling at another mould station
2,Efficient automation: Ease of integration with complex production cells as the mould area is easily accessible from all sides
3,Simple and precise insertion and holding of parts in cavities thanks to horizontal mould parting line.
4,Ergonomic operation: The table height offers ultimate ergonomics for manual parts handling. A raised work platform for the operating staff is not typically necessary.
5,Short handling times Safe and time-saving highly secure access to mould area thanks to a light curtain: no two-handed operation required to move the clamping unit and ejector
6,Highly-sensitive injection process control:the electronic controller for the hydraulic injection unit and the clamped system of the injection piston guarantee excellent mould part quality and reproduction.
7,Energy savings Thanks to clamping pressure lock-in,low-friction guide elements and electro-hydraulic control pumps.the energy consumption is already very low. The use of the intelligent servo hydraulic eco-drive helps to drastically reduce energy consumption-and thus cooling water consumption-on top .
| Specifications: |
|
| BETTER 1200SD-3RT Vertical LSR injection molding machine |
| clamping force |
120tons |
| size |
1290*560mm |
| max mold size |
550*550mm |
| Min mold height |
120mm |
| mold stroke |
280mm |
| max daylight |
400mm |
| ejector force |
3tons |
| Thimble diameter |
Φ25 |
| ejector distance(product) |
300mm |
| Max hydraulic pressure |
140kg/cm2 |
| cooling water |
1500-1800liters/hr |
| ElectrothermaL |
4kw |
| Motor |
15kw |
| Dimention (L*W*H) |
2.28*2.6*3.12/3.86 |
| weight |
7.4tons |
Characteristics
1,Compared with the solid rubber molding, the liquid silica gel injection molding does not need the operation procedures such as molding, mixing, pre molding, etc., which saves manpower, material resources and energy, reduces equipment investment and floor space.
2,The injection molding of liquid silica gel can realize the automatic processing under the fully closed condition, eliminate the manual operation deviation, reduce the influence and pollution of various variable factors in the processing, and ensure the dimensional accuracy and internal quality of the product, which is conducive to the application of liquid silica gel in medical treatment.
3,Because the viscosity of liquid silica gel is very low (generally in the range of 10-1000pas), and its fluidity and processability are good, its injection pressure is much lower than that of solid rubber and plastic. Generally, the injection pressure is 20MPa, which can be lower than 1MPa in some cases. Therefore, it can produce products without flash, reduce material waste, and reduce the wear of equipment and mold. In addition, due to the good fluidity of liquid silica gel, it is especially suitable for forming large-scale products, extremely complex shape products or ultra-thin products, such as ultra-thin products with a forming thickness of 0.5mm and a length of 100mm, which is difficult for solid rubber materials to form.
4,The curing rate of liquid silica gel is very fast. During injection molding, the curing reaction can be completed in the range of 160-220 seconds to several minutes, so the molding cycle is short and the production efficiency is high.
5,The back pressure required for liquid silica gel in screw metering is very small, generally less than 1.5MPa. For some liquid silica gel materials with very low viscosity, even no back pressure can be set, which is mainly due to the good fluidity of low viscosity silica gel and the low gas content in liquid silica gel in normal operation. On the contrary, the large back pressure will increase the density of the unvulcanized silica gel and destroy the accurate measurement effect of the metering device.
6,Liquid silica gel does not shrink in the process of injection molding, but due to its high thermal expansion coefficient, it usually shrinks by 2% ~ 3% after demoulding and cooling. The exact shrinkage data depends on the material formula. From the point of view of processing, designers should consider some factors affecting shrinkage in advance.
